| Parameter | Specification |
|---|---|
| Chassis Parameters | |
| Chassis Model | ISUZU GIGA heavy-duty chassis |
| Drive Type | 6×4 |
| Emission Standard | Euro VI |
| Engine | ISUZU inline 6-cylinder 4-stroke turbo diesel engine |
| Max. Power | 280 kW (380 HP) @ 2200 rpm |
| Max. Torque | 1420 N·m @ 1200–1600 rpm |
| Transmission | 12-speed manual gearbox |
| Cab | Sleeper cab with A/C, power windows and central locking |
| Tire Specification | 12R22.5 steel radial tires |
| Fuel Tank Capacity | 300 L |
| Aerial Work Performance | |
| Max. Working Height | 60 m |
| Max. Working Radius | 30 m |
| Platform Rated Load | 250 kg |
| Platform Size | 1200 × 800 × 1150 mm |
| Boom Structure | 5-section telescopic main boom + fly jib |
| Slewing Angle | 360° continuous rotation |
| Platform Rotation | ±90° |
| Outrigger Type | H-type full-span outriggers with independent control |
| Max. Outrigger Width | 6.5 m |
| Control Mode | Dual-station control (ground + basket), electro-hydraulic proportional |
| Dimensions & Weight | |
| Overall Length | 13800 mm |
| Overall Width | 2550 mm |
| Overall Height (stowed) | 3980 mm |
| Gross Vehicle Weight | 31000 kg |
| Curb Weight | 29200 kg |
| Safety Configuration | |
| Standard | Overload protection, tilt alarm, emergency lowering, emergency stop, outrigger interlock, boom anti-collision limit |
| Optional | Height limiter, camera monitoring system, wireless remote control |
