Your products's number
| Basic Information | |
| Drive type: | 8X4 |
| Wheelbase: | 1850+2980/4575+1370MM / 2100+4325+1370mm |
| engine: | Japanese brands engine |
| Transmission: | FSAT |
| Vehicle length: | 10000mm / 10500mm / 11000mm |
| Vehicle width: | 2.55 meters |
| Vehicle height: | Based on actual height |
| Front track: | 2140/2140mm |
| Rear track: | 1855/1855mm |
| Maximum speed: | 89km/h |
| fuel tank capacity | 600L |
| Place of origin: | China |
| Tonnage class: | Heavy trucks |
| Energy type: | diesel fuel |
| Engine parameters | |
| Engine brand: | Japanese brands |
| Engine horsepower | 300HP/350HP/380HP/420HP/460HP/520HP |
| Number of cylinders: | 6 cylinders |
| Fuel type: | diesel fuel |
| Cylinder arrangement: | inline |
| Displacement: | 15.681L |
| Maximum output power: | 220kw/257kw/279kw/308kw/338kw/382kw |
| Transmission parameters | |
| Gearbox brand: | FAST series |
| Gear shifting method: | Hand-in-hand |
| Forward gear: | 9 gears / 12 gears |
| Number of reverse gears: | 2nd gear |
| Transmission fluid capacity | 13.5L |
| Cab parameters | |
| Driver's cab: | Japanese brands-GIGA |
| Passenger capacity: | 2 people |
| Driver's seat configuration: | Mechanical Seat |
| Chassis parameters | |
| Front axle allowable load: | 7500 / 9000kg |
| Rear axle allowable load: | 18000 (two-axis assembly) kg |
| Speed ratio: | |
| tire | |
| Tire specifications: | 295/80R22.5 315+385/80R22.5 16PR |
| Number of tires: | 12 plus 1 spare tire |
| Crane Information | |
| Crane Brands | XuGong |
| Crane Model | GSQZ560.8 |
| Maximum lifting mass | 28000Kg |
| Maximum lifting moment | 490kN.M |
| Maximum reach arm length | 20.80m |
| Number of hydraulic telescopic booms | 8articulated arm |
| Amplitude range | 0~76° |
| Rotation angle | endless |
| outrigger stride | 2342-8216mm |
| Product weight | 7350kg |
| Recommended hydraulic flow rate | 80L/min |
| Maximum working pressure | 32 MPa |
| Ambient oil temperature range | below zero25℃~40℃ |
| Hydraulic oil tank capacity | 300L |
| Operation method | Manual/Remote Control |
